100KW 75Kvar 380VAC RLC Dry Load Bank for Generator Testing 3 phase

Name: 100KW 75Kvar 380VAC RLC Dry Load Bank for Generator Testing 3 phase
Brand: FULLDE
Price: 1 USD

China 100KW 75Kvar 380VAC RLC Dry Load Bank for Generator Testing 3 phase wholesale

Brand Name : FULLDE

Model Number : LB-100KW/75KVAR/75KVA-380VAC

Certification : CE, ISO9001

Place of Origin : Dongguan,China

MOQ : one set

Price : US $3,000 - 10,000 / Set

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 100 Set/Sets per Month

Delivery Time : 25 working days

Packaging Details : Wooden packaging,Carton packaging

Testing Voltage : 3 phase 4wires 380VAC/50HZ

Power Factor : 0.8~1.0

Dimension : 1000*1300*1600mm

Cooling : Forced air cooling

Working environment : Indoors or outdoors

Contact Now

100KW 75Kvar 380VAC RLC Dry Load Bank for Generator Testing

Introduction:

Power generator intelligent testing system can accurately test the output power and loading capacity of various generator units,test all the electric parameters including dynamic parameters of generator units,and mainly consists of two parts:testing control and load cabinet,which is used in coordination with host computer thus materializing intelligentization and automatization to complete the testing of all electric parameters of generator unit,meanwhile,charts,curves and testing report are produced,and no manual operation is required(intelligently controlled,manual/automatic may be selected),to provide scientific testing means for large power generator units.

Technical Parameters

System Composition	Resistor, air cooling, the electric parameters testing, control panel
Resistor Element	Special alloy resistance, high temperature resistance, corrosion resistance, high precision, long service life, resistance tolerance is ±5%;
Connection	The three-phase four wire system, star connection method, copper;
Control	Contactor
Control Voltage	Three Phases, 380VAC,50Hz；
Dimension(mm)	100013001600mm；
Weight	about 400KG
Load element type	Pure resistive
Control	Local manual control;
Load Tolerance	±5%；
Way of Working	Continuous working；
Cooling type	Force air cooling;
Insulation grade	F；
Protection	1. Emergency Stop: User can press the emergency stop button in the panel to unload immediately when the load bank is abnormal while working; 2. Short Circuit Protection: Fuse could avoids damage to equipment when short circuit or current overload; 3. Fan Air Quantity Protection: when the wind is insufficient, the machine will unload and give alarm;
Protection Button	there are protection button both in local control and remote control can be switched off when false alarm or for special requirements.
Protection Grade	IP23；
Transportation	Rings on the top or caster wheels;

Software Interface Picture:

100KW 75Kvar 380VAC RLC Dry Load Bank for Generator Testing 3 phase
