375KVA Mobile Resistive Reactive Load Bank For Marine Industial Generator Test

Name: 375KVA Mobile Resistive Reactive Load Bank For Marine Industial Generator Test
Brand: Fullde
Price: 1 USD

Brand Name : Fullde

Model Number : LB-375KVA-400VAC-J

Certification : CE, ISO9001

Place of Origin : Dongguan,China

MOQ : one set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50 sets per month

Delivery Time : 15 working days

Packaging Details : Packaged by Wooden Case with Soft Protective Material

Rating voltage/frequency : 400VAC 3 phase 4 wire, 50Hz

Relative Humidity : ≤95%

Accessories : Switch: ABB, Siemens and Schneider, PLC: Panasonic and Siemens;

Dimensions : 2000*2400*2400

Load Tolerance (inductive load) : ±3%

Load Tolerance (resistive load) : ±5%

Contact Now

375KVA Movable Resistive Reactive Load Bank for Generator Testing in Marine

Main Functions:

(1) Load Bank Testing: User could load any power within rated power to test the output performance of generator set;
(2) Control Mode: With total load control function,can complete the sudden increase or decrease of load of any percentage(intelligently controlled,manual/automatic can be selected);
(3) Over-heat protection: There will be sound-light alarm when temperature is over safety thresholds.

Specification
Rating voltage/frequency	400VAC 3 phase 4 wire, 50Hz
Max Load Power	Apparent Power: 375kVA
Max Load Power	Resistive Load: 2400kW; Inductive Load: 1800kvar
Load Resolution	Resistive Load: 1KW/2KW/2KW/5KW/10KW/10KW/20KW/50KW/100KW/100KW
Load Resolution	Inductive Load: 11 steps, 1Kvar/2Kvar/2Kvar/5Kvar/5Kvar/10Kvar/10Kvar/20Kvar/20Kvar/50Kvar/100Kvar,225Kvar
Power Factor	0.8
Load Tolerance (resistive load)	±5%
Load Tolerance (inductive load)	±3%
Fan Control Power	110V/220V,50Hz/60Hz
Wire Connection	Load bank input——Copper bar
Wire Connection	Control power input——Connector-bar
Max Protection Grade	IP54
Way of Working	Continuous Working
Cooling	Forced air cooling, horizontal inlet air and upwards exhaust cooling
Transportation	Hoisting
Color	RAL7032
Dimensions	200024002400
Weight	1500KG
Accessories	Switch: ABB, Siemens and Schneider, PLC: Panasonic and Siemens;
Operating Environment Parameter
Ambient Temperature	-10℃~+50℃
Relative Humidity	≤95%

FAQ:
1. Are you manufacturer?
Yes, we are professional manufacturer of gas generator with 11 years’ experience.

2. What about the product quality?
a) Each generator will be strictly tested before delivery and offer cutomers test report.
b) Noise level tested 70~75db.
c) Operation of the various meters on the control panel.

3. What about the price?
We provide the reasonable price. Different power have different price. More discount can talked further.

4. Can you arrange the installation?
Yes, we exported to India, Germany, and Africa etc. And some of them installed by our technology team.

5. Can you accept special order?
Yes, we have R&D center with years’ experience for load banks. Welcome to visit us. You will
get the best service and product.

We do believe our company will be best choice among the Chinese load banks company.
