Surface Mount High Power Resistor , Aluminum Housed Wire Wound Resistor

Product Categories

Guangdong Fullde Electrical Technology Co., Ltd

Contact Now

Name: Surface Mount High Power Resistor Aluminum Housed Wire Wound Resistor
Brand: FULLDE
Price: 1 USD

Brand Name : FULLDE

Model Number : FD-WR-10KW

Certification : RoHS CE ISO9001

Place of Origin : Dongguan,China

MOQ : one

Price : US $1.00-US$6

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 35000 Piece/Pieces per Week

Delivery Time : 3-4 working days

Packaging Details : Cartons

Type : Fixed Resistor

Technology : Wirewound

Package Type : Surface Mount

Rated Power : 15W-10KW

Color : Grey

Material : Ceramic Tube Wirewound

Resistor : Surface Mount Wirewound Resistors

Application : Electronic Product

OEM : Available

Product Name : Braking resistor

Contact Now

Variable Resistive Dummy Load Bank Made of Aluminum Housed Wire Wound Resistor

Applications:

Elevator, port machinery, rolling mills, hoist the generator, inverter and other brake and load

Use of the environment:
Rated temperature (+70 °C); use with the temperature range (-55 °C ~ +375 °C)

Structure:
Rated power temperature (+70 °C); use with the temperature range (-55 °C ~ +375 °C)

Applicable standards: GB/T5729-2003 GB5732-85

The main test items, test methods and performance requirements
Test items	Performance requirements	Test methods
Temperature coefficient of resistance	≤±250(×10-6/°C)	-55°C/+20°C,20°C/+125°C
Terminal Strength	R≤±(1%R+0.05Ω)	Pull 20N
Dielectric	No breakdown or flashover	2500V DC,1min
Weldability	Solder to flow freely and with terminals infiltration	235±5°C2±0.5s
Resistance to soldering heat	ΔR≤±(1%R+0.05Ω)	260±5°C10±1s
Short-time overload	ΔR≤±(2%R+0.05Ω)	10 times the rated power, 5s
Rapid changes in temperature	ΔR≤±(1%R+0.05Ω)	-55 °C / +125 °C 5 cycles
Vibration	ΔR≤±(1%R+0.05Ω)	10~500Hz98m/s2
Long-term load	ΔR≤±(2%R+0.05Ω)	+70±2°C VR 1000h
Non-flammable	Not burning	1 to 6 times the rated power for 5 minutes
Surface temperature rise	≤350°C	The rated power
Insulation resistance value	1000MΩ	1000V DC

Packing Drawing:

Product Tags:

high wattage resistors
